PM Toolkit

Overview

PM Toolkit is a personal product management intelligence system that transforms an Obsidian vault (markdown files with YAML frontmatter) into a polished, web-based strategic planning dashboard. It provides complete strategy-to-execution traceability for individual PMs who want to own their data, maintain full strategic visibility, and generate stakeholder-ready artifacts without a database or SaaS platform.

Core value proposition: Screenshots and exports look professional enough to share directly with stakeholders — no additional formatting needed.

Target users: Individual product managers using Obsidian + Jira/Workboard, who want a unified view from customer signals through strategy to shipped outcomes.

Key Features

• Strategy graph visualization (React Flow, dagre layout) with interactive node/edge manipulation
• Changelog with PostHog-style horizontal timeline
• Customer signals pipeline with vectors, KANO grid, and Cost-of-Delay matrix
• Now-Next-Later kanban planning
• Opportunity Solution Tree (5-level hierarchy)
• Outcome measurement with impact tracking
• Bidirectional sync with Jira, Workboard, GitHub, and Miro
• Daily task management with Obsidian integration and write-back
• Cross-team strategy mapping
• Data analytics with computed metrics and auto-updating KPIs
• Newsletter builder with auto-rendering
• Multiple export formats (PDF, PNG, Markdown)
• Obsidian plugin with validation, linting, quick capture
• Chrome extension for Jira/Confluence capture
• CLI for sync, reporting, and changelog generation

Architecture

Tech Stack

Layer	Technology
Framework	Next.js 16.1.6 (App Router)
UI	React 19.2.3 + Tailwind CSS v4 + shadcn/ui
Visualization	React Flow 12.10 + dagre 2.0 + d3-* libraries + Mermaid 11.12
Validation	Zod 4.3.6
Content	gray-matter (YAML frontmatter), js-yaml
CLI	Commander.js
Export	Puppeteer 24.36 + html-to-image + Handlebars
Testing	Vitest 4.0 + @testing-library/react
Monorepo	pnpm 10.29 workspaces
Build	esbuild (plugins), tsup (CLI/packages)

Monorepo Structure

pmtoolkit/
├── src/                    # Next.js web app (App Router)
│   ├── app/                # Route pages (changelog/, signals/, vectors/, strategy/, etc.)
│   ├── components/         # React components (dashboard, strategy graph, charts)
│   ├── lib/
│   │   ├── content/        # Vault reading, config, markdown parsing
│   │   ├── tasks/          # Daily note scanning, task parsing, task actions
│   │   ├── dashboard/      # Aggregators (task, discovery, okr, activity)
│   │   ├── miro/           # MiroClient, mapping, types
│   │   └── jira/           # Jira sync state, manifest builders
│   ├── actions/            # Server actions (write-back)
│   └── types/              # TypeScript interfaces
├── packages/
│   ├── shared-schemas/     # Zod schemas for all 23 content types
│   ├── cli/                # pmt CLI binary
│   ├── obsidian-plugin/    # Obsidian plugin (esbuild)
│   ├── chrome-extension/   # Chrome extension (MV3)
│   ├── jira-client/        # Jira Cloud API client
│   ├── workboard-client/   # Workboard API client
│   ├── github-client/      # GitHub API client
│   └── miro-client/        # Miro API client
├── demo-content/           # Bundled Obsidian vault for demo mode
├── templates/              # Obsidian Templater templates
└── .planning/              # Planning docs, milestones, requirements

Key Design Patterns

1. Markdown Source of Truth — All content is YAML-frontmatter markdown in Obsidian vault. Web app reads files, never modifies vault directly during normal operation.
2. Server-Side Aggregation + Client Components — Dashboard computation in server components; clients receive pre-computed props.
3. Sync State Files — .pmtoolkit/sync-state/ tracks bidirectional sync with external tools, prevents re-processing.
4. Schema Registry — Zod SCHEMA_REGISTRY maps 23 content types to their schemas for exhaustive type checking.
5. Line-Level Write-Back — Task mutations use string surgery with expectedRawLine guard for conflict detection.
6. Config Unification — Single Zod schema in shared-schemas consumed by web, CLI, and Obsidian plugin with per-platform secret storage.

Data Flow

Reading: Obsidian Vault → readVaultContent() → Schema validation (Zod) → Dashboard aggregators (server-side) → React components (client-side)

Writing: User interaction → Server action → Line-level string surgery with expectedRawLine guard → Sync state update → revalidatePath() → Next.js cache invalidation

Integration: Web/CLI reads config → API client (OAuth/token auth) → Sync state comparison for conflict detection → Frontmatter update or rejection → Obsidian reads fresh files

Development History

Timeline: 70 days (Feb 3 - Apr 13, 2026), 18 shipped milestones + v3.4 (7/10 phases complete), 354+ completed plans, 2,122 total commits.

Version	Date	Focus
v1.0	Feb 3	Foundation, Changelog, PRDs, Stakeholder Mapping, Export
v1.1	Feb 4	Strategy content types, React Flow visualization
v1.2	Feb 6	Universal edit mode, KR parsing, dashboard
v1.3	Feb 7	Signals/Vectors/Customers, KANO grid, Cost of Delay
v1.4	Feb 8	Strategy detail pages, Now-Next-Later kanban
v1.5	Feb 9	Monorepo, Obsidian plugin, Chrome extension
v1.6	Feb 11	Daily note task parsing, time-bucket kanban, write-back
v1.7	Feb 14	Workboard bidirectional sync
v1.8	Feb 19	Jira Cloud sync, sprint reporting
v1.9	Feb 21	OST, outcome measurement, GitHub integration
v2.0	Feb 22	Clustering board, newsletter builder, Miro export
v2.1	Feb 27	Strategy canvas, experiment management
v2.2	Feb 28	Teams, cross-team strategy map
v3.0	Mar 1	Dataset loading, metric computation, KR auto-update
v3.1	Mar 1	Jira UX overhaul, traceability chains, KPI health cascade
v3.2	Mar 13	Daily signal extraction, weekly dashboard, Miro CLI
v3.3	Apr 10	Sustainability & self-awareness — SQLite usage analytics + heatmap, nav consolidation (30 → 20 items), TypeScript cleanup (110+ errors), demo mode infrastructure with feedback DB and 5 validation UI components, demo vault pruned 143 → 77 files
v3.4	In progress	Team GitHub activity analysis — multi-repo config, team discovery, commit/tag wiring, contributor stats, cycle time, Copilot detection, Jira cross-referencing, multi-repo changelog. 7 of 10 phases complete (117-123); Phase 124 (OKR/KR restructuring) in progress

Structural Shift: Key Results as First-Class Entities (Phase 124, April)

The most significant architectural change post-profile is a data model correction: Key Results were promoted from inline OKR sub-objects to first-class file-backed entities under strategy/key-results/. OKR files now hold a keyResults: [slug] array only. The canonical strategy-theory.md (edited April 12) reframes OKRs as grouping, not structural — KRs become the team-level execution citizens, with edges to initiatives and KPIs.

Cascading refactor: schemas, canvas, Workboard sync, migration CLI, templates, web components. This is not feature creep — it's a conceptual correction surfaced after 70 days of dogfooding. "The data model was inverted" is a legitimate v3.4 insight and the kind of thing that only emerges from sustained real use.

Architectural Decisions

Decision	Rationale
Markdown over database	User data ownership, portability, version control
YAML frontmatter over JSON	Single file per entity, self-contained, Obsidian native
Server actions for write-back	Avoids API layer, leverages Next.js, direct file access
Monorepo over separate repos	Shared types, consistent CLI patterns, monolithic release
Custom API clients (not SDKs)	Fine-grained control, rate limiting, retry logic, ~300-400 LOC each
Line-level write-back	Fine-grained mutations preserve manual edits
Puppeteer for export	Proven PDF quality, singleton browser pool

Strengths

• Complete strategy-to-execution traceability — North Stars through OKRs to measured outcomes; unique vs. commercial PM tools
• Signal-to-vector discovery pipeline — Evidence-driven prioritization with KANO/Cost-of-Delay scoring
• File-based portability — Zero lock-in, git-friendly, user controls backup
• Bidirectional sync — Content-hash conflict detection, echo prevention, explicit merge strategy per field
• Export quality — Stakeholder-ready PDFs, PNGs, and Markdown without post-processing
• Comprehensive testing — 43+ test files, 47 tests for task parser alone

Weaknesses & Risks

• Tag parsing collision risk — Task parser and signal extractor both scan daily notes for #tags
• Config unification can break credentials — Three config systems with incompatible assumptions need careful migration
• Weekly dashboard O(N) scanning — Aggregators read all daily notes synchronously; mitigated with date filtering and ISR
• TODO write-back race conditions — Two rapid toggles on same task could read stale line content
• Sync state complexity — Partial failure leaves inconsistent state; needs atomic writes
• Schema registry breaks on new content types — Adding types requires updates to enum, registry, Obsidian detector, switch cases
• External validation still not executed — v3.3 shipped demo mode, feedback DB, and validation session UI, but no external PMs have used the tool yet. The March 23 recommendation to "find 2-3 PMs and watch them try it" is still outstanding one month later. The velocity continues without user validation

Prompting Patterns

The project documents clear AI collaboration patterns in dear-new-pm.md:

1. Signal Synthesis — Copy 10-15 signals, ask Claude to group into vectors, compare AI vs. human groupings
2. Strategy Stress-Testing — Export strategy graph, ask for assumption identification and gap analysis
3. PRD Drafting — Provide vector + connected signals + target OKR, ask for problem section draft
4. Sprint Narrative — Provide sprint summary data, ask for executive summary
5. Prioritization Challenge — Copy scored vectors + OKRs, ask if prioritization aligns

Anti-patterns explicitly warned against: AI cannot replace customer relationships, AI confidently generates plausible-but-wrong strategy, AI hallucinates connections, velocity trap (producing more artifacts faster while real bottleneck is judgment).
